Checkline 3000PRO Coating Thickness Gauge

Manufacturer: Checkl

---

Warranty: One Year

---

The new Check-L 3000PRO Series coating thickness gauge is a multifunctional fully menu driven gauge for fast, professional and precise coating thickness measurement for:

• paint and electroplated coatings on iron and steel
• paint and anodizing coatings on non-ferrous metals and on austenitic stainless steels

The user will select the model best suited for their application. All the probes are interchangeable and their internal calibration is stored within a small microchip inside the probe connector housing. This provides for quick and easy hot-swapping from one probe to any other in seconds.

Six (6) different models are offered for a wide variety of applications.

Kit Contents

3000PRO Coating Thickness Gauge Probe Manufacturers calibration certificate Ferrous and or non-errous zero plate (model dependant) 2 calibration foils 2 AA batteries Soft pouch Instruction manual Plastic carrying case

Features

• Automatic identification of the substrate
• Calibration-free measurements (calibration only in exceptional cases)
• Mobile and stationary operation with only one gauge
• Highly wear-resistant measuring poles made of carbide metal
• The 3000PRO Coating Thickness Gauge features special probes for unusual measurement tasks
• Precise measurements on different geometries thanks to simple calibration methods
• Safe use even for special applications such as sand-blasted surfaces, small parts and curved surfaces
• Scan mode for the quick recognition of coating thickness variations on large surfaces, including display of minimum and maximum readings
• Display backlight for bad ambient lighting conditions
• Onl statistics with all statistical parameters
• Easy to operate, well-known from mobile phones
• Intuitive menu guidance via dialog with the user
• Free choice of language German, English, French
• Extensive data memory for the management of different measurement series
• Alphanumerical file names can be individually stored for every measurement task
• Infrared interface for wireless data transfer to printer and PC
• No additional data transfer software required thanks to the use of Windows standard application (HyperTerminal)
• Optional high temperature footer for measuring on surfaces up to 150 C/302 F
• The 3000PRO Coating Thickness Gauge includes NIST Calibration Certificate
• 1 Year Warranty

Specifications

Measuring principle	Magnetic induction method (F-version); Eddy current method (N-version)
Measuring range	3000PRO & 3000PRO-FN90:0 - 60.00 mils / 0 - 1500 m 3000PRO-F10: 0 - 400 mils / 0 - 10,000 m
Tolerance	(0.7 m/0.04 mils + 1% of reading)
Resolution	Refer to RESOLUTION TABLE, above
Display	4-digit display (digit height 10 mm/0.4") and 32 alphanumerical characters; switchable backlight
Minimum measurement area	5 mm x 5mm/0.2" x 0.2"
Minimum curvature radius	convex 2mm/0.08"; concave 5mm/0.2"
Minimum substrate thickness	0.2mm/8 mils (for F-versions); 50 m/2 mils (for N-versions)
Calibration methods	Factory calibration: no calibration required for standard applications Zeroing (1-point calibration): measurements on small geometries Zeroing and foil calibration (2-point calibration): increased measuring accuracy Two-foil calibration: especially for rough, sand-blasted surfaces CTC: calibration on coated object if zeroing is not possible Zero offset: addition/subtraction of a constant value to/from the reading
Limit values	Selectable; optical and acoustic signal if limit value is exceeded
Scan mode	For continuous measurements; for the quick recognition of coating thickness variations; with permanent display of minimum and maximum reading
Statistics	Single-value statistics: n, avarage x, s, kvar, min, max, cp, cpk from max. 10,000 readings Block-value statistics: n, avarage x , avarage s, avarage kvar , min, max, cp, cpk; block size 3 to 100 readings
Data memory	10,000 readings in max. 500 selectable files; alphanumerical file names; stored readings and statistical values individually recallable
Interfaces	Infrared and serial RS232 interface
Language	Operator prompting and documentation in German, English, French (optional other languages)
Operating temperature	0 C to 50 C/32 F to 122 F (storage temperature - 20 C to +60 C/-4 F to 140 F)
Surface temperature	5 F - 140 F / -15 C - 60 C (standard) 5 - 302 F / 15 - 150 C (w/optional footer)
Power supply	2 x round cell (AA) 1.5 V up to 60 hours of operating time
Housing/keypad	Protection class IP52 (protection against dust and dripping water)
Dimensions	Gauge: 140 mm x 62 mm x 30mm/5.6" x 2.5" x 1.2" (HxWxD) Probe: dia. 14 mm x 83mm/dia. 0.56" x 3.3"
Weight	approx. 200 g/7 oz (gauge including batteries and probe)
Standards	DIN EN ISO, ASTM, BS
Warranty	1 Year
Calibration Certificate	Included

Available Probes

"F" Probes measure Coatings on Ferrous Metals
"N" Probes measure Coatings on Non-Ferrous Metals
"FN" Probes measure Coatings on both Ferrous & Non-Ferrous Metals

Resolution Table

Standard probe & and FN/90 probe
Mils
0.00 - 9.99 mils	0.01 mils
10.00 - 24.98 mils	0.02 mils
25.00 - 49.95 mils	0.05 mils
50.0 - 99.9 mils	0.1 mils
Microns (m)
0.0 - 99.9 m	0.1 m
100.0 - 249.8 m	0.2 m
250.0 - 499.5 m	0.5 m
500 - 999 m	1 m
1.000 - 1.998 mm	0.002 mm
